As the latest innovation from C&D Emerging Energy, the GMC Inverter Charger is purpose-built to meet the growing demands of modern mobile power systems. Engineered for use in recreational vehicles, specialty vehicles, and marine applications, it delivers exceptional performance with high efficiency, strong surge capability, and intelligent multi-stage charging.The GMC inverter charger features seamless automatic switching between AC and DC systems, ensuring uninterrupted power supply. It also integrates a main battery charger and a CAN-BUS communication port, enabling advanced system monitoring and interactive control to meet a wide range of user requirements.Built to perform in harsh conditions, the unit operates reliably at temperatures up to 50°C, maintaining full power output without derating or interruption. Durable, intelligent, and versatile, the GMC inverter charger is the ideal solution for mobile and off-grid power applications.
MODEL
GMC 2000
GMC 3000
GMC 4000
GMC 5000
GMC 6000
Raled Power
2000W
3000W
4000W
5000W
6000W
INPUT
Voltage
100V110V120VAC; 220/230V240VAC
Selectable Voltage Range
Wide Range: 75VAC-138VAC; 155VAC-275VAC (for home appliances)Narrow Range: 82VAC-138VAC: 165VAC-275VAC (for personal computer)
Frequency
40-70Hz
100/110V/120VAC(±5W); 220V/230V240VAC(±10V)
OUTPUT
AC Voltage Regulation(Batt Mode)
100/110/120VAC(±5W); 220/230/240VAC(±10V)
Surge PoAer
4000VA
9000VA
12000VA
15000VA
18000VA
Efficiency (Peak)
88%
91%
Transher Time
<20ms
< 10ms
Wave form
Pure sine wave
BATTERY
Battery Voltage
12V/24V
12V/24V/48V
24V/48V
24V/48V
24V/48V
Charge curent
75A/35A
75A/50A/25A
75A/35A
75A/45A
75A/50A
Fast Charge Voltage
14.3VDC for 12V(*2 for 24V. *4 for 48V)
Float Charge Voltage
13.7VDC for 12V(*2 for 24V. *4 for 48V)
Battery Low Voltage Alarm
16.5VDC for 12V(*2 for 24V. *4 for 48V)
Over Voltage Protection
10.5VDC for 12V(*2 for 24V. *4 for 48V)
Battery low Voltage Shutdown
10.0VDC for 12V(*2 for 24V. *4 for 48V)
Protection
Over charging, Over temp, Over battery voltage, Over load, short-circult
Operating EnvironmentTemperature
50℃
Cooling
Intelligent Fan
Display
LCD
Specification Setting
By LCD:Charging current, battery type, input voltage, output frequency, wide and narrowof AC input voltage, power-saver model, AC priority or battery priority
PHYSICAL
Dimension. (D"V"H)mm
532*257*185.5
617.5*345*199.5
Net weight (kg)
15
25.2/24.6
34.4/33.8
37.9/38.2
41.6/40.5
ENVIRONMENT
Humidity
5-95 Relative humidity (No-condensing)
Operating Temperature
-10°C-50°C
Storage Temperature
-10°C-60°C
